NEMA 4X JIC Style Hinge Cover Wall Mount Enclosures
Premium UL Listed JIC Style NEMA 4X enclosures built for the harshest industrial environments. JIC Style enclosures come in single door and are limited to hinge style wall mount types that are 16" or smaller in height or width.
Choose from 304 stainless steel, 316 stainless steel, or 5052 aluminum for maximum flexibility. 304 stainless provides reliable corrosion resistance for most applications. 316 stainless steel offers superior protection in saltwater, chemical, and coastal environments. 5052 aluminum delivers lightweight durability with excellent corrosion resistance at a cost-effective price point.
Key Features:
- 12 to 16 gauge 304, 316 stainless steel or .125 5052 aluminum construction
- Suitable for wet, outdoor, and corrosive environments
- Optional white baked enamel back panel
- NEMA standards compliant and UL/cUL Listed (508A)
- Fully customizable configurations
- Piano SS hinge, continuously welded seams, SS mounting tabs
- Clamps only for the locking mechanism
- Made in Randolph, MA - BABA certs on request
Perfect for food processing, breweries, dairies, chemical plants, pharmaceutical facilities, offshore installations, and marine applications requiring washdown protection and corrosion resistance.
Build your custom NEMA 4X enclosure at CustomNEMAEnclosures.com. Select your preferred material, configure exact dimensions, and specify features with our online configurator.
